The laboratory unit is a desktop enclosure with an electric diagram depicted on its frontal panel. The diagram has connecting jacks for assembling circuits and connect-ing measuring devices. Circuit assembling is implemented using plug jumpers.
A USB-oscilloscope is used for measurements.
The training system is supplied with:
a set of technical and methodical documentation for teaching staff.
Studying the properties of ferroelectrics.
~50 Hz 220 V (single-phase 220 V 50 Hz)
Power consumption, kW, max
Stand overall dimensions, max
Weight, kg, max
Scope of delivery
laboratory stand – 1 pc.;
connecting jumpers – 1 set;
measuring module – 1 pc.;
passport – 1 pc.;
accompanying materials in electronic format – 1 pc.
