NTC-23.63 “The study of the refrigerating unit”

Br0.00

The laboratory training system is designed for carrying out laboratory works in universities and secondary technical educational establishments for the study of industrial refrigeration equipment and its operation.


Category:
Structurally the stand consists of control and indicating device and test board.

The measuring part of the stand contains electricity meter and digital devices displaying compressor input and output pressure, condenser and evaporator input and output temperature, temperature in the movable box with the polycarbonate walls (cooled space).

Pressure and temperature gauges are built in cooling fluid loop. USB interface for data exchange with PC is mounted on control and measurement panel. The information displayed on the devices of the stand can be processed by PC.

The stand is accompanied with a set of teaching materials and technical documentation intended for the teaching staff.

Experiments provided

  1. Refrigerating machines.
  2. Safety during maintenance of low-temperature refrigerating machines.
  3. Operating parameters of refrigerating machines.
  4. Determination of the refrigerating cycle parameters.

Technical specifications

Power supply: 1~220V, 50 Hz
Power consumption, kW, max 1,5
Control and indicating device overall dimensions, max:
  Width, mm 650
  Height, mm 1470
  Depth, mm 660
Test board overall dimensions, max:
  Width, mm 800
  Height, mm 1470
  Depth, mm 2600
Weight, kg, max 130

Scope of delivery

  • training laboratory system – 1 pc.;
  • passport – 1 pc.;
  • supplementary materials in electronic format – 1 pc.
