The training laboratory system is mounted on a mobile platform includes three elements:

an imitation of a urinal with radar electronics,
a no-touch urinal flushing device,
a wash sink mixer with an optical sensor.

The system is equipped with a water feed system, a network connector with a flowmeter, a water disposal system (50mm drain pipe). The devices are connected with flexible hoses with isolation valves, the mixer is installed on a wash sink with a flushing device, water disposing is provided.

The training system is supplied with technical and methodical documentation intended for teaching staff.

3D model

Experiments provided

Plumbing equipment with electronic control.
Installation and operation.
Characteristics of sensor mixer and flush actuators.

Technical specifications

Power supply		~50Hz 220V batteries АА/ААА
Power consumption, kW, max		0,2
Stand overall dimensions, max:
	Width, mm	1600
	Height, mm	1900
	Depth, mm	800
Weight, kg, max		80

Scope of delivery

training laboratory system – 1 pc.;
multifunctional electrical parameters meter – 1 pc.;
passport – 1 pc.;
accompanying materials in electronic format – 1 pc.

Additional equipment

Recommended additional equipment:

tools set.

NTC-16.48 “Electronic plumbing fixtures”
